8.2.1 Flower Assembly

Overview

The flower assembly is the canonical “reverse-explosion” animation: an image is divided into a grid of tiles, the tiles are scattered to random positions off the canvas, and then they fly back into their correct positions to assemble the original image. It looks like a complicated effect; mechanically it is just interpolation between two known positions for each of $N^2$ tiles, with an easing curve to make the arrival look organic.

The technique is the cousin of every “logo reveal” animation in motion graphics, every text-by-text assembly in title sequences, and the visual basis of the explosion-played-backwards sequence in Christopher Nolan’s Tenet (2020). For us, it’s the first time in Module 08 that we animate many things at once — each tile is a small animation, and the composition is a render pass that composes all of them every frame.

Learning objectives

1. Slice an image into a regular grid of tiles using NumPy array indexing.
2. Generate per-tile random start positions in polar coordinates (angle + radius) and convert to Cartesian offsets.
3. Interpolate each tile’s position from its scatter point to its home position via an ease-out cubic curve.
4. Render the composite frame by blitting each translated tile into a fresh canvas.

Quick start — a 16×16 flower assembly

import numpy as np
from PIL import Image

N_TILES, N_FRAMES, SCATTER_RADIUS = 16, 60, 350

flower = np.array(Image.open('flower.png').convert('RGB'))
H, W, _ = flower.shape
th, tw = H // N_TILES, W // N_TILES

# Per-tile arrays: home position + scatter offset
home_yx = np.array([(r * th, c * tw) for r in range(N_TILES) for c in range(N_TILES)])
rng = np.random.default_rng(7)
angles = rng.uniform(0, 2 * np.pi, len(home_yx))
radii = rng.uniform(SCATTER_RADIUS * 0.5, SCATTER_RADIUS, len(home_yx))
scatter_dyx = np.stack([(radii * np.sin(angles)).astype(int),
                        (radii * np.cos(angles)).astype(int)], axis=1)

frames = []
for f in range(N_FRAMES):
    t = f / (N_FRAMES - 1)
    progress = 1 - (1 - t) ** 3                       # ease-out cubic
    offsets = (scatter_dyx * (1 - progress)).astype(int)
    canvas = np.full(flower.shape, 12, dtype=np.uint8)
    for (cy, cx), (dy, dx) in zip(home_yx, offsets):
        y, x = cy + dy, cx + dx
        if 0 <= y <= H - th and 0 <= x <= W - tw:
            canvas[y:y+th, x:x+tw] = flower[cy:cy+th, cx:cx+tw]
    frames.append(Image.fromarray(canvas))

frames[0].save('flower_assembly.gif', save_all=True,
               append_images=frames[1:], duration=50, loop=0)

Core concepts

Concept 1 — Slicing the image into tiles

A grid of N × N tiles is N² non-overlapping rectangular crops:

tile[r, c] = image[r * th : (r+1) * th, c * tw : (c+1) * tw]

where th = H // N and tw = W // N. NumPy slicing returns views, not copies, so storing all $N²$ tiles costs nothing in memory until you write into them. For a 512×512 image at $N = 16$, each tile is 32×32 — small enough to render thousands per frame at interactive rates.

Concept 2 — Scatter offsets in polar coordinates

Random positions tend to clump in the corners of a bounding rectangle. Random directions are uniformly distributed around the circle. The polar form gives the more even-looking scatter:

angles = rng.uniform(0, 2 * np.pi, n_tiles)
radii = rng.uniform(R_min, R_max, n_tiles)
scatter_dy = (radii * np.sin(angles)).astype(int)
scatter_dx = (radii * np.cos(angles)).astype(int)

The R_min cushion prevents tiles from starting too close to their home positions (which would look static); R_max controls how far they travel. For an off-canvas scatter, R_max should exceed the canvas half-diagonal.

Concept 3 — Per-tile interpolation with ease-out

At each frame, every tile’s offset from home shrinks from scatter_offset (at t = 0) to 0 (at t = 1):

offset(t) = scatter_offset * (1 - easing(t))

Ease-out cubic — $1 - (1 - t)^3$ — is the natural choice: the tiles fly in fast and decelerate as they arrive, which looks like they have inertia. Ease-in would be wrong (slow arrival followed by sudden snap). Linear works but feels mechanical. The whole animation hinges on this easing call.

Exercises

Three exercises in Execute → Modify → Create order: render the default assembly, sweep parameters, then add per-tile rotation.

# inside the frame loop, after computing progress and offsets:
for i, ((cy, cx), (dy, dx)) in enumerate(zip(home_yx, offsets)):
    y, x = cy + dy, cx + dx
    if not (0 <= y <= H - th and 0 <= x <= W - tw):
        continue

    tile_arr = flower[cy:cy+th, cx:cx+tw]
    tile_img = Image.fromarray(tile_arr)

    # TODO 1: pick a per-tile random start_rotation (e.g., uniform in [-180, 180])
    #         (store these outside the frame loop, computed once)

    # TODO 2: current rotation = start_rotation * (1 - progress)

    # TODO 3: rotate the tile and paste into the canvas (canvas is now a PIL image)

# Before the frame loop:
start_rotations = rng.uniform(-180, 180, len(home_yx))
canvas_image = Image.new('RGB', (W, H), (12, 12, 12))

angle = start_rotations[i] * (1 - progress)
rotated = tile_img.rotate(angle, expand=True, resample=Image.BILINEAR)
# Centre the rotated tile on its destination centre
ry, rx = y + th // 2, x + tw // 2
rh, rw = rotated.size[1], rotated.size[0]
canvas_image.paste(rotated, (rx - rw // 2, ry - rh // 2))

Downloads

Summary

Common pitfalls to avoid

• Random Cartesian scatter. Looks rectangular; biases toward the diagonals. Always use polar (angle + radius) for circular scatter.
• Ease-in for arrival. Wrong direction — the tiles slow at the start and snap home. Always ease-out for arriving motion.
• No bounds check. Tiles flying off-canvas during animation would crash the index assignment. Skip blits with out-of-range destinations.
• No held frames at the end. The viewer can’t tell the animation finished without a pause to see the completed image.
