8.4.3 Animated Fractals

Overview

A static Mandelbrot render (4.1.3) is beautiful but is a single window into an infinitely deep mathematical object. Adding the dimension of time unlocks the fractal’s most hypnotic property: the infinite zoom. Each frame is the same Mandelbrot computation with a smaller view window centred on a fixed interesting point. With exponential interpolation of the window size, the apparent dive feels constant-velocity even though the absolute distance to the “bottom” of the well is geometrically shrinking.

This lesson is the capstone of Module 08. Every technique you have built — easing, interpolation, per-frame rendering, GIF assembly — composes here into a single 90-frame zoom animation. The destination is a 500× zoom on “Seahorse Valley” at $(-0.7436, 0.1318)$, one of the most photographed regions of the Mandelbrot boundary.

Learning objectives

1. Parameterise the Mandelbrot view window as a function of frame index using exponential zoom interpolation.
2. Compute the per-frame iteration limit so detail scales with zoom depth.
3. Map iteration counts to RGB colour with a smooth gradient palette.
4. Assemble all frames into an animated GIF with Pillow’s save_all + append_images.

Quick start — Mandelbrot zoom

import numpy as np
from PIL import Image

def mandelbrot_frame(width, height, x_min, x_max, y_min, y_max, max_iter):
    x = np.linspace(x_min, x_max, width)
    y = np.linspace(y_min, y_max, height)
    X, Y = np.meshgrid(x, y)
    C = X + 1j * Y
    Z = np.zeros_like(C)
    iterations = np.zeros(C.shape)
    for i in range(max_iter):
        mask = np.abs(Z) <= 2
        Z[mask] = Z[mask] ** 2 + C[mask]
        iterations[mask] = i
    return iterations

cx, cy = -0.7436, 0.1318
frames = []
for f in range(60):
    progress = f / 59
    width = 3.0 * (500 ** (-progress))
    img = mandelbrot_frame(400, 400,
                            cx - width / 2, cx + width / 2,
                            cy - width / 2, cy + width / 2,
                            150)
    rgb = np.stack([img / 150 * 255,
                    (img / 150 * 128).astype(np.uint8),
                    (255 - img / 150 * 200).astype(np.uint8)], axis=-1)
    frames.append(Image.fromarray(rgb.astype(np.uint8)))

frames[0].save('zoom.gif', save_all=True, append_images=frames[1:], duration=33, loop=0)

Core concepts

Concept 1 — Exponential zoom interpolation

Linear interpolation of the view window width — width = initial × (1 − progress) — produces a non-uniform perception: the early frames look like the camera is zooming slowly, the later frames feel like it’s stopping. The reason is Weber’s law of perception: equal absolute changes feel different at different magnitudes. A 5% width change at full scale feels different from a 5% change at 100× zoom.

The fix is exponential interpolation:

width(f) = initial_width × zoom_factor^(-progress)

Each frame’s window is a fixed fraction of the previous frame’s window. The eye reads this as constant velocity because each frame “feels” like the previous one with the camera one step closer. The same exponential perception applies to every zoom animation in cinema, every “endless tunnel” effect, every navigable map zoom on Google Maps.

def view_window(frame, total_frames, cx, cy, init_w, zoom):
    progress = frame / (total_frames - 1)
    w = init_w * (zoom ** -progress)
    return (cx - w / 2, cx + w / 2, cy - w / 2, cy + w / 2)

Concept 2 — Iteration depth scales with zoom

The deeper you zoom, the more iterations you need to resolve the fractal boundary. Points that escape after, say, 30 iterations are colourful at 1× zoom but look like a solid wedge at 100× zoom — because every pixel in the visible region escapes between the same handful of iteration counts.

Rule of thumb: for zoom factor $Z$, use roughly $\log_2(Z) \cdot 50$ iterations as a minimum. For a 500× zoom, that’s $\log_2(500) \cdot 50 \approx 450$ iterations. The cost grows; the visual fidelity grows with it.

You can also scale iterations per frame — start at 150 for the wide view and ramp up to 450 by the final frame. This saves CPU on the early frames where detail isn’t needed.

Concept 3 — Colour palette and rendering

Iteration counts map to colours via a per-channel gradient. A simple gradient produces the look of static Mandelbrot renders; a more sophisticated palette gives the zoom video its character:

def iterations_to_rgb(iterations, max_iter):
    normalized = iterations / max_iter
    rgb = np.zeros(iterations.shape + (3,), dtype=np.uint8)
    inside = iterations >= (max_iter - 1)
    # Cool palette: purple → cyan
    rgb[..., 0] = np.where(inside, 0, (normalized * 200).astype(np.uint8))
    rgb[..., 1] = np.where(inside, 0, (normalized * 100).astype(np.uint8))
    rgb[..., 2] = np.where(inside, 0, (255 - normalized * 200).astype(np.uint8))
    return rgb

The black region (points in the Mandelbrot set) is inside == True. Everything else gets a colour proportional to its escape rate. Try variations:

• Fire: red high, green moderate, blue low.
• Ocean: blue high, green low, red minimal.
• Cyclic rainbow: sin(normalized * 10 + offset) per channel for a banded look that emphasises the iso-iteration curves.

Exercises

Three exercises in Execute → Modify → Create order: run the default zoom, sweep parameters, then code the rendering pipeline from scratch.

import numpy as np
from PIL import Image

def compute_mandelbrot(width, height, x_min, x_max, y_min, y_max, max_iter):
    # TODO 1: create the complex grid with meshgrid
    # TODO 2: iterate z = z² + c with boolean masking
    # TODO 3: return the iteration counts
    pass

def iterations_to_colors(iterations, max_iter):
    # TODO 4: convert counts to RGB; inside-set points are black
    pass

def zoom_window(frame, total_frames, cx, cy, init_w, zoom):
    # TODO 5: exponential interpolation of the window width
    pass

def render_animation(cx, cy, zoom, n_frames):
    frames = []
    for f in range(n_frames):
        xmin, xmax, ymin, ymax = zoom_window(f, n_frames, cx, cy, 3.0, zoom)
        iters = compute_mandelbrot(400, 400, xmin, xmax, ymin, ymax, 200)
        rgb = iterations_to_colors(iters, 200)
        frames.append(Image.fromarray(rgb))
    return frames

def compute_mandelbrot(width, height, x_min, x_max, y_min, y_max, max_iter):
    x = np.linspace(x_min, x_max, width)
    y = np.linspace(y_min, y_max, height)
    X, Y = np.meshgrid(x, y)
    C = X + 1j * Y
    Z = np.zeros_like(C, dtype=np.complex128)
    iterations = np.zeros(C.shape, dtype=np.float64)
    for i in range(max_iter):
        mask = np.abs(Z) <= 2
        Z[mask] = Z[mask] ** 2 + C[mask]
        iterations[mask] = i
    return iterations

def iterations_to_colors(iterations, max_iter):
    n = iterations / max_iter
    rgb = np.zeros(iterations.shape + (3,), dtype=np.uint8)
    inside = iterations >= max_iter - 1
    rgb[..., 0] = np.where(inside, 0, (n * 200).astype(np.uint8))
    rgb[..., 1] = np.where(inside, 0, (n * 100).astype(np.uint8))
    rgb[..., 2] = np.where(inside, 0, (255 - n * 200).astype(np.uint8))
    return rgb

def zoom_window(frame, total_frames, cx, cy, init_w, zoom):
    progress = frame / (total_frames - 1)
    w = init_w * (zoom ** -progress)
    return (cx - w / 2, cx + w / 2, cy - w / 2, cy + w / 2)

Downloads

Summary

Common pitfalls to avoid

• Linear zoom. Reads as jarring acceleration. Always exponential.
• Static iteration count. Too few = blurred deep frames; too many = unnecessary cost on shallow frames. Scale with depth.
• Black-on-black palette mistakes. Points inside the Mandelbrot set should be black; check inside mask is correct.
• Per-pixel Python loops in the palette. Render times balloon. Vectorise with NumPy np.where.
